Gamme L
Cornières
Cornières à ailes égalesDimensions
EN10056-1: 1998
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 20 x 20 x 3 | 0,9 | 20,0 | 20,0 | 3,0 | 3,0 | 3,5 | 1,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 25 x 25 x 3 | 1,1 | 25,0 | 25,0 | 3,0 | 3,0 | 3,5 | 1,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 25 x 25 x 4 | 1,5 | 25,0 | 25,0 | 4,0 | 4,0 | 3,5 | 1,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 30 x 30 x 3 | 1,4 | 30,0 | 30,0 | 3,0 | 3,0 | 5,0 | 1,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 30 x 30 x 4 | 1,8 | 30,0 | 30,0 | 4,0 | 4,0 | 5,0 | 2,30 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 35 x 35 x 4 | 2,1 | 35,0 | 35,0 | 4,0 | 4,0 | 5,0 | 2,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 40 x 40 x 4 | 2,4 | 40,0 | 40,0 | 4,0 | 4,0 | 6,0 | 3,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 40 x 40 x 5 | 3,0 | 40,0 | 40,0 | 5,0 | 5,0 | 6,0 | 3,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 45 x 45 x 4.5 | 3,1 | 45,0 | 45,0 | 4,5 | 4,5 | 7,0 | 3,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 50 x 50 x 4 | 3,1 | 50,0 | 50,0 | 4,0 | 4,0 | 7,0 | 3,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 50 x 50 x 5 | 3,8 | 50,0 | 50,0 | 5,0 | 5,0 | 7,0 | 4,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 50 x 50 x 6 | 4,5 | 50,0 | 50,0 | 6,0 | 6,0 | 7,0 | 5,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 55 x 55 x 5 | 4,2 | 55,0 | 55,0 | 5,0 | 5,0 | 8,0 | 5,30 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 60 x 60 x 5 | 4,6 | 60,0 | 60,0 | 5,0 | 5,0 | 8,0 | 5,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 60 x 60 x 6 | 5,4 | 60,0 | 60,0 | 6,0 | 6,0 | 8,0 | 6,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 60 x 60 x 8 | 7,1 | 60,0 | 60,0 | 8,0 | 8,0 | 8,0 | 9,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 65 x 65 x 5 | 5,0 | 65,0 | 65,0 | 5,0 | 5,0 | 9,0 | 6,30 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 65 x 65 x 7 | 6,8 | 65,0 | 65,0 | 7,0 | 7,0 | 9,0 | 8,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 70 x 70 x 5 | 5,4 | 70,0 | 70,0 | 5,0 | 5,0 | 9,0 | 6,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 70 x 70 x 6 | 6,4 | 70,0 | 70,0 | 6,0 | 6,0 | 9,0 | 8,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 70 x 70 x 7 | 7,4 | 70,0 | 70,0 | 7,0 | 7,0 | 9,0 | 9,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 75 x 75 x 5 | 5,8 | 75,0 | 75,0 | 5,0 | 5,0 | 9,0 | 7,30 | 38 | 7,0 | 1,0 | 2,30 | 39 | 7,0 | 1,0 | 2,30 |
| L 75 x 75 x 6 | 6,9 | 75,0 | 75,0 | 6,0 | 6,0 | 10,0 | 8,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 75 x 75 x 8 | 8,9 | 75,0 | 75,0 | 8,0 | 8,0 | 10,0 | 11,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 80 x 80 x 5 | 6,2 | 80,0 | 80,0 | 5,0 | 5,0 | 5,0 | 7,90 | 47 | 8,0 | 1,0 | 2,45 | 47 | 8,0 | 1,0 | 2,45 |
| L 80 x 80 x 8 | 9,7 | 80,0 | 80,0 | 8,0 | 8,0 | 10,0 | 12,30 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 80 x 80 x 10 | 11,9 | 80,0 | 80,0 | 10,0 | 10,0 | 10,0 | 15,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 90 x 90 x 5 | 7,0 | 90,0 | 90,0 | 5,0 | 5,0 | 11,0 | 8,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 90 x 90 x 7 | 9,6 | 90,0 | 90,0 | 7,0 | 7,0 | 11,0 | 12,20 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 90 x 90 x 8 | 10,9 | 90,0 | 90,0 | 8,0 | 8,0 | 11,0 | 13,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 90 x 90 x 9 | 12,2 | 90,0 | 90,0 | 9,0 | 9,0 | 11,0 | 15,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 90 x 90 x 10 | 13,4 | 90,0 | 90,0 | 10,0 | 10,0 | 11,0 | 17,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 100 x 100 x 7 | 10,8 | 100,0 | 100,0 | 7,0 | 7,0 | 7,0 | 13,70 | 128 | 18,0 | 1,0 | 3,06 | 128 | 18,0 | 1,0 | 3,06 |
| L 100 x 100 x 8 | 12,2 | 100,0 | 100,0 | 8,0 | 8,0 | 12,0 | 15,50 | 144 | 20,0 | 1,0 | 1,00 | 145 | 20,0 | 1,0 | 1,00 |
| L 100 x 100 x 10 | 15,1 | 100,0 | 100,0 | 10,0 | 10,0 | 12,0 | 19,20 | 176 | 25,0 | 1,0 | 1,00 | 177 | 25,0 | 1,0 | 1,00 |
| L 100 x 100 x 12 | 17,8 | 100,0 | 100,0 | 12,0 | 12,0 | 12,0 | 22,70 | 206 | 29,0 | 1,0 | 3,02 | 207 | 29,0 | 1,0 | 3,02 |
| L 110 x 110 x 8 | 13,4 | 110,0 | 110,0 | 8,0 | 8,0 | 12,0 | 17,10 | 195 | 24,0 | 1,0 | 3,38 | 195 | 24,0 | 1,0 | 3,38 |
| L 110 x 110 x 9 | 15,0 | 110,0 | 110,0 | 9,0 | 9,0 | 12,0 | 19,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 110 x 110 x 10 | 16,6 | 110,0 | 110,0 | 10,0 | 10,0 | 13,0 | 21,20 | 238 | 30,0 | 1,0 | 3,35 | 238 | 30,0 | 1,0 | 3,35 |
| L 110 x 110 x 12 | 19,7 | 110,0 | 110,0 | 12,0 | 12,0 | 13,0 | 25,10 | 279 | 36,0 | 1,0 | 3,33 | 279 | 36,0 | 1,0 | 3,33 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 120 x 120 x 8 | 14,7 | 120,0 | 120,0 | 8,0 | 8,0 | 13,0 | 18,70 | 255 | 29,0 | 1,0 | 3,69 | 255 | 29,0 | 1,0 | 3,69 |
| L 120 x 120 x 9 | 16,5 | 120,0 | 120,0 | 9,0 | 9,0 | 13,0 | 21,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 120 x 120 x 10 | 18,2 | 120,0 | 120,0 | 10,0 | 10,0 | 13,0 | 23,20 | 312 | 36,0 | 1,0 | 3,67 | 313 | 36,0 | 1,0 | 3,67 |
| L 120 x 120 x 11 | 19,9 | 120,0 | 120,0 | 11,0 | 11,0 | 13,0 | 25,40 | 340 | 39,0 | 1,0 | 3,66 | 341 | 39,0 | 1,0 | 3,66 |
| L 120 x 120 x 12 | 21,6 | 120,0 | 120,0 | 12,0 | 12,0 | 13,0 | 27,50 | 367 | 43,0 | 1,0 | 3,65 | 368 | 43,0 | 1,0 | 3,65 |
| L 120 x 120 x 13 | 23,3 | 120,0 | 120,0 | 13,0 | 13,0 | 13,0 | 29,70 | 394 | 46,0 | 1,0 | 3,64 | 394 | 46,0 | 1,0 | 3,64 |
| L 120 x 120 x 15 | 26,6 | 120,0 | 120,0 | 15,0 | 15,0 | 13,0 | 33,90 | 444 | 52,0 | 1,0 | 3,62 | 445 | 52,0 | 1,0 | 3,62 |
| L 120 x 120 x 16 | 28,3 | 120,0 | 120,0 | 16,0 | 16,0 | 13,0 | 36,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 130 x 130 x 12 | 23,6 | 130,0 | 130,0 | 12,0 | 12,0 | 14,0 | 30,00 | 472 | 50,0 | 1,0 | 3,97 | 472 | 50,0 | 1,0 | 3,97 |
| L 140 x 140 x 10 | 21,4 | 140,0 | 140,0 | 10,0 | 10,0 | 15,0 | 27,20 | 504 | 49,0 | 1,0 | 4,30 | 504 | 49,0 | 1,0 | 4,30 |
| L 140 x 140 x 12 | 25,5 | 140,0 | 140,0 | 12,0 | 12,0 | 15,0 | 32,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 140 x 140 x 13 | 27,4 | 140,0 | 140,0 | 13,0 | 13,0 | 15,0 | 35,00 | 638 | 63,0 | 1,0 | 4,27 | 639 | 63,0 | 1,0 | 4,27 |
| L 140 x 140 x 14 | 29,4 | 140,0 | 140,0 | 14,0 | 14,0 | 15,0 | 37,50 | 1.780 | 254,0 | 301,0 | 5,60 | 645 | 92,0 | 145,0 | 3,37 |
| L 140 x 140 x 15 | 31,4 | 140,0 | 140,0 | 15,0 | 15,0 | 15,0 | 40,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 150 x 150 x 10 | 23,0 | 150,0 | 150,0 | 10,0 | 10,0 | 16,0 | 29,30 | 624 | 57,0 | 1,0 | 4,62 | 624 | 57,0 | 1,0 | 4,62 |
| L 150 x 150 x 11 | 25,2 | 150,0 | 150,0 | 11,0 | 11,0 | 16,0 | 32,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 150 x 150 x 12 | 27,3 | 150,0 | 150,0 | 12,0 | 12,0 | 16,0 | 34,80 | 736 | 68,0 | 1,0 | 4,60 | 737 | 68,0 | 1,0 | 4,60 |
| L 150 x 150 x 13 | 29,5 | 150,0 | 150,0 | 13,0 | 13,0 | 16,0 | 37,60 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 150 x 150 x 14 | 31,6 | 150,0 | 150,0 | 14,0 | 14,0 | 16,0 | 40,30 | 845 | 78,0 | 1,0 | 4,58 | 845 | 78,0 | 1,0 | 4,58 |
| L 150 x 150 x 15 | 33,8 | 150,0 | 150,0 | 15,0 | 15,0 | 16,0 | 43,00 | 898 | 84,0 | 1,0 | 4,57 | 898 | 84,0 | 1,0 | 4,57 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 150 x 150 x 16 | 36,0 | 150,0 | 150,0 | 16,0 | 16,0 | 16,0 | 45,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 150 x 150 x 18 | 40,1 | 150,0 | 150,0 | 18,0 | 18,0 | 16,0 | 51,00 | 1.050 | 99,0 | 1,0 | 4,54 | 1.050 | 99,0 | 1,0 | 4,54 |
| L 150 x 150 x 20 | 44,2 | 150,0 | 150,0 | 20,0 | 20,0 | 16,0 | 56,30 | 1.146 | 109,0 | 1,0 | 4,51 | 1.146 | 109,0 | 1,0 | 4,51 |
| L 152 x 152 x 9.5 | 22,1 | 152,0 | 152,0 | 9,5 | 9,5 | 0,0 | 28,10 | 637 | 57,0 | 1,0 | 4,75 | 638 | 57,0 | 1,0 | 4,75 |
| L 152 x 152 x 15.9 | 36,0 | 152,0 | 152,0 | 15,9 | 15,9 | 0,0 | 45,90 | 1.004 | 93,0 | 1,0 | 4,68 | 1.004 | 93,0 | 1,0 | 4,68 |
| L 160 x 160 x 14 | 33,9 | 160,0 | 160,0 | 14,0 | 14,0 | 17,0 | 43,20 | 1.034 | 90,0 | 1,0 | 4,89 | 1.034 | 90,0 | 1,0 | 4,89 |
| L 160 x 160 x 15 | 36,2 | 160,0 | 160,0 | 15,0 | 15,0 | 17,0 | 46,10 | 1.099 | 96,0 | 1,0 | 4,88 | 1.099 | 96,0 | 1,0 | 4,88 |
| L 160 x 160 x 16 | 38,4 | 160,0 | 160,0 | 16,0 | 16,0 | 17,0 | 49,00 | 1.163 | 101,0 | 1,0 | 4,87 | 1.163 | 101,0 | 1,0 | 4,87 |
| L 160 x 160 x 17 | 40,7 | 160,0 | 160,0 | 17,0 | 17,0 | 17,0 | 51,80 | 1.225 | 107,0 | 1,0 | 4,86 | 1.225 | 107,0 | 1,0 | 4,86 |
| L 160 x 160 x 18 | 42,9 | 160,0 | 160,0 | 18,0 | 18,0 | 17,0 | 54,60 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 160 x 160 x 19 | 45,1 | 160,0 | 160,0 | 19,0 | 19,0 | 17,0 | 57,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 160 x 160 x 20 | 47,3 | 160,0 | 160,0 | 20,0 | 20,0 | 17,0 | 60,30 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 13 | 35,7 | 180,0 | 180,0 | 13,0 | 13,0 | 18,0 | 45,50 | 1.396 | 107,0 | 1,0 | 5,54 | 1.396 | 107,0 | 1,0 | 5,54 |
| L 180 x 180 x 14 | 38,3 | 180,0 | 180,0 | 14,0 | 14,0 | 18,0 | 48,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 15 | 40,9 | 180,0 | 180,0 | 15,0 | 15,0 | 18,0 | 52,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 16 | 43,5 | 180,0 | 180,0 | 16,0 | 16,0 | 18,0 | 55,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 17 | 46,1 | 180,0 | 180,0 | 17,0 | 17,0 | 18,0 | 58,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 18 | 48,6 | 180,0 | 180,0 | 18,0 | 18,0 | 18,0 | 61,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 19 | 51,1 | 180,0 | 180,0 | 19,0 | 19,0 | 18,0 | 65,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 180 x 180 x 20 | 53,7 | 180,0 | 180,0 | 20,0 | 20,0 | 18,0 | 68,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 180 x 180 x 22 | 58,6 | 180,0 | 180,0 | 22,0 | 22,0 | 18,0 | 74,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 13 | 39,8 | 200,0 | 200,0 | 13,0 | 13,0 | 18,0 | 50,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 14 | 42,7 | 200,0 | 200,0 | 14,0 | 14,0 | 18,0 | 54,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 15 | 45,6 | 200,0 | 200,0 | 15,0 | 15,0 | 18,0 | 58,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 16 | 48,5 | 200,0 | 200,0 | 16,0 | 16,0 | 18,0 | 61,80 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 17 | 51,4 | 200,0 | 200,0 | 17,0 | 17,0 | 18,0 | 65,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 18 | 54,2 | 200,0 | 200,0 | 18,0 | 18,0 | 18,0 | 69,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 19 | 57,1 | 200,0 | 200,0 | 19,0 | 19,0 | 18,0 | 72,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 20 | 59,9 | 200,0 | 200,0 | 20,0 | 20,0 | 18,0 | 76,30 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 21 | 62,7 | 200,0 | 200,0 | 21,0 | 21,0 | 18,0 | 79,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 22 | 65,5 | 200,0 | 200,0 | 22,0 | 22,0 | 18,0 | 83,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 23 | 68,4 | 200,0 | 200,0 | 23,0 | 23,0 | 18,0 | 87,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 24 | 71,4 | 200,0 | 200,0 | 24,0 | 24,0 | 18,0 | 91,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 25 | 73,9 | 200,0 | 200,0 | 25,0 | 25,0 | 18,0 | 94,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 26 | 76,6 | 200,0 | 200,0 | 26,0 | 26,0 | 18,0 | 97,60 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 200 x 28 | 82,0 | 200,0 | 200,0 | 28,0 | 28,0 | 18,0 | 104,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 203 x 203 x 12.7 | 39,3 | 203,0 | 203,0 | 12,7 | 12,7 | 0,0 | 50,00 | 2.021 | 137,0 | 1,0 | 6,36 | 2.021 | 137,0 | 1,0 | 6,36 |
| L 203 x 203 x 14.3 | 44,0 | 203,0 | 203,0 | 14,3 | 14,3 | 0,0 | 56,00 | 2.249 | 153,0 | 1,0 | 6,33 | 2.249 | 153,0 | 1,0 | 6,33 |
| L 203 x 203 x 15.9 | 48,7 | 203,0 | 203,0 | 15,9 | 15,9 | 0,0 | 62,00 | 2.471 | 169,0 | 1,0 | 6,31 | 2.471 | 169,0 | 1,0 | 6,31 |
| L 203 x 203 x 19.0 | 57,8 | 203,0 | 203,0 | 19,1 | 19,1 | 0,0 | 73,60 | 2.900 | 199,0 | 1,0 | 6,27 | 2.900 | 199,0 | 1,0 | 6,27 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 203 x 203 x 22.2 | 66,7 | 203,0 | 203,0 | 22,2 | 22,2 | 0,0 | 85,00 | 3.310 | 229,0 | 1,0 | 6,23 | 3.310 | 229,0 | 1,0 | 6,23 |
| L 203 x 203 x 25.4 | 76,0 | 203,0 | 203,0 | 25,4 | 25,4 | 0,0 | 96,80 | 3.693 | 258,0 | 1,0 | 6,18 | 3.693 | 258,0 | 1,0 | 6,18 |
| L 203 x 203 x 28.6 | 84,8 | 203,0 | 203,0 | 28,6 | 28,6 | 0,0 | 108,00 | 4.071 | 287,0 | 1,0 | 6,14 | 4.071 | 287,0 | 1,0 | 6,14 |
| L 250 x 250 x 18 | 67,8 | 250,0 | 250,0 | 18,0 | 18,0 | 18,0 | 86,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 20 | 75,7 | 250,0 | 250,0 | 20,0 | 20,0 | 18,0 | 96,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 21 | 79,3 | 250,0 | 250,0 | 21,0 | 21,0 | 18,0 | 101,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 22 | 83,2 | 250,0 | 250,0 | 22,0 | 22,0 | 18,0 | 106,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 23 | 86,4 | 250,0 | 250,0 | 23,0 | 23,0 | 18,0 | 110,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 24 | 90,3 | 250,0 | 250,0 | 24,0 | 24,0 | 18,0 | 115,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 25 | 93,4 | 250,0 | 250,0 | 25,0 | 25,0 | 18,0 | 119,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 26 | 97,3 | 250,0 | 250,0 | 26,0 | 26,0 | 18,0 | 124,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 27 | 100,5 | 250,0 | 250,0 | 27,0 | 27,0 | 18,0 | 128,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 250 x 250 x 28 | 104,4 | 250,0 | 250,0 | 28,0 | 28,0 | 18,0 | 133,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L x 250 x 250 x 19 | 107,2 | 250,0 | 250,0 | 19,0 | 19,0 | 18,0 | 136,50 | 7 | 443,0 | 1,0 | 7.858,00 | 8 | 443,0 | 1,0 | 7.858,00 |
| L 250 x 250 x 30 | 110,7 | 250,0 | 250,0 | 30,0 | 30,0 | 18,0 | 141,00 | 8.087 | 457,0 | 1,0 | 7,57 | 8.087 | 457,0 | 1,0 | 7,57 |
| L 250 x 250 x 31 | 114,1 | 250,0 | 250,0 | 31,0 | 31,0 | 18,0 | 145,40 | 8.313 | 471,0 | 1,0 | 7,56 | 8.313 | 471,0 | 1,0 | 7,56 |
| L x 250 x 250 x 32 | 117,5 | 250,0 | 250,0 | 32,0 | 32,0 | 18,0 | 149,70 | 8.536 | 484,0 | 8,0 | 1,00 | 8.536 | 484,0 | 8,0 | 1,00 |
| L 250 x 250 x 33 | 121,0 | 250,0 | 250,0 | 33,0 | 33,0 | 18,0 | 154,10 | 8.757 | 498,0 | 8,0 | 1,00 | 8.757 | 498,0 | 8,0 | 1,00 |
| L 250 x 250 x 34 | 124,3 | 250,0 | 250,0 | 34,0 | 34,0 | 18,0 | 158,40 | 8.975 | 512,0 | 8,0 | 1,00 | 8.975 | 512,0 | 8,0 | 1,00 |
| L 250 x 250 x 35 | 128,0 | 250,0 | 250,0 | 35,0 | 35,0 | 18,0 | 163,00 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 254 x 254 x 19.0 | 73,1 | 254,0 | 254,0 | 19,0 | 19,0 | 18,0 | 93,10 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 254 x 254 x 22.2 | 84,7 | 254,0 | 254,0 | 22,2 | 22,2 | 18,0 | 107,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 254 x 254 x 25.4 | 96,2 | 254,0 | 254,0 | 25,4 | 25,4 | 19,0 | 122,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 254 x 254 x 28.6 | 107,7 | 254,0 | 254,0 | 28,6 | 28,6 | 19,0 | 137,20 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 254 x 254 x 31.2 | 118,8 | 254,0 | 254,0 | 31,2 | 31,2 | 19,0 | 151,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 300 x 300 x 25 | 112,0 | 300,0 | 300,0 | 25,0 | 25,0 | 18,0 | 142,70 | 12.150 | 561,0 | 9,0 | 1,00 | 12.150 | 561,0 | 9,0 | 1,00 |
| L 300 x 300 x 26 | 116,3 | 300,0 | 300,0 | 26,0 | 26,0 | 18,0 | 148,20 | 12.590 | 583,0 | 9,0 | 1,00 | 12.590 | 583,0 | 9,0 | 1,00 |
| L 300 x 300 x 27 | 120,7 | 300,0 | 300,0 | 27,0 | 27,0 | 18,0 | 153,70 | 13.020 | 604,0 | 9,0 | 1,00 | 13.020 | 604,0 | 9,0 | 1,00 |
| L 300 x 300 x 28 | 124,9 | 300,0 | 300,0 | 28,0 | 28,0 | 18,0 | 159,10 | 13.450 | 625,0 | 9,0 | 1,00 | 13.450 | 625,0 | 9,0 | 1,00 |
| L 300 x 300 x 29 | 129,2 | 300,0 | 300,0 | 29,0 | 29,0 | 18,0 | 164,60 | 13.870 | 645,0 | 9,0 | 1,00 | 13.870 | 645,0 | 9,0 | 1,00 |
| L 300 x 300 x 30 | 133,5 | 300,0 | 300,0 | 30,0 | 30,0 | 18,0 | 170,00 | 14.290 | 666,0 | 9,0 | 1,00 | 14.290 | 666,0 | 9,0 | 1,00 |
| L 300 x 300 x 31 | 137,7 | 300,0 | 300,0 | 31,0 | 31,0 | 18,0 | 175,40 | 14.700 | 686,0 | 9,0 | 1,00 | 14.700 | 686,0 | 9,0 | 1,00 |
| L 300 x 300 x 32 | 141,8 | 300,0 | 300,0 | 32,0 | 32,0 | 18,0 | 180,70 | 15.120 | 707,0 | 9,0 | 1,00 | 15.120 | 707,0 | 9,0 | 1,00 |
| L 300 x 300 x 33 | 146,1 | 300,0 | 300,0 | 34,0 | 34,0 | 18,0 | 186,10 | 15.520 | 727,0 | 9,0 | 1,00 | 15.520 | 727,0 | 9,0 | 1,00 |
| L 300 x 300 x 34 | 150,2 | 300,0 | 300,0 | 34,0 | 34,0 | 18,0 | 191,40 | 15.930 | 748,0 | 9,0 | 1,00 | 15.930 | 748,0 | 9,0 | 1,00 |
| L 300 x 300 x 35 | 154,4 | 300,0 | 300,0 | 35,0 | 35,0 | 18,0 | 196,70 | 16.320 | 767,0 | 9,0 | 1,00 | 16.320 | 767,0 | 9,0 | 1,00 |
| L 305 x 305 x 25.4 | 115,6 | 305,0 | 305,0 | 25,4 | 25,4 | 19,0 | 147,20 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 305 x 305 x 31.2 | 143,2 | 305,0 | 305,0 | 31,2 | 31,2 | 19,0 | 182,40 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 120 x 80 x 8 | 12,2 | 120,0 | 80,0 | 8,0 | 8,0 | 11,0 | 15,50 | 225 | 28,0 | 1,0 | 3,82 | 81 | 13,0 | 1,0 | 2,28 |
| L 120 x 80 x 10 | 15,0 | 120,0 | 80,0 | 10,0 | 10,0 | 11,0 | 19,10 | 275 | 34,0 | 1,0 | 1,00 | 98 | 16,0 | 1,0 | 1,00 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 120 x 80 x 12 | 17,8 | 120,0 | 80,0 | 12,0 | 12,0 | 11,0 | 22,70 | 322 | 40,0 | 1,0 | 1,00 | 114 | 19,0 | 1,0 | 1,00 |
| L 130 x 65 x 8 | 11,8 | 130,0 | 65,0 | 8,0 | 8,0 | 11,0 | 15,10 | 262 | 31,0 | 1,0 | 1,00 | 45 | 9,0 | 1,0 | 1,00 |
| L 130 x 65 x 10 | 14,6 | 130,0 | 65,0 | 10,0 | 10,0 | 11,0 | 18,60 | 320 | 38,0 | 1,0 | 1,00 | 54 | 11,0 | 1,0 | 1,00 |
| L 150 x 75 x 9 | 15,4 | 150,0 | 75,0 | 9,0 | 9,0 | 12,0 | 19,60 | 455 | 47,0 | 1,0 | 4,82 | 78 | 13,0 | 1,0 | 1,99 |
| L 150 x 75 x 10 | 17,0 | 150,0 | 75,0 | 10,0 | 10,0 | 12,0 | 21,70 | 500 | 52,0 | 1,0 | 4,81 | 85 | 15,0 | 1,0 | 1,99 |
| L 150 x 75 x 11 | 18,6 | 150,0 | 75,0 | 11,0 | 11,0 | 12,0 | 23,70 | 545 | 56,0 | 1,0 | 4,80 | 93 | 16,0 | 1,0 | 1,98 |
| L 150 x 75 x 12 | 20,2 | 150,0 | 75,0 | 12,0 | 12,0 | 12,0 | 25,70 | 588 | 61,0 | 1,0 | 4,78 | 100 | 17,0 | 1,0 | 1,97 |
| L 150 x 90 x 10 | 18,2 | 150,0 | 90,0 | 10,0 | 10,0 | 12,0 | 23,20 | 533 | 53,0 | 1,0 | 1,00 | 146 | 21,0 | 1,0 | 1,00 |
| L 150 x 90 x 11 | 19,9 | 150,0 | 90,0 | 11,0 | 11,0 | 12,0 | 25,30 | 580 | 58,0 | 1,0 | 1,00 | 159 | 23,0 | 1,0 | 1,00 |
| L 150 x 90 x 12 | 21,6 | 150,0 | 90,0 | 12,0 | 12,0 | 12,0 | 27,50 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 150 x 90 x 15 | 26,6 | 150,0 | 90,0 | 15,0 | 15,0 | 12,0 | 33,90 | 761 | 1,0 | 1,0 | 4,74 | 206 | 1,0 | 1,0 | 2,46 |
| L 150 x 100 x 10 | 19,0 | 150,0 | 100,0 | 10,0 | 10,0 | 12,0 | 24,20 | 552 | 54,0 | 1,0 | 1,00 | 199 | 26,0 | 1,0 | 1,00 |
| L 150 x 100 x 12 | 22,5 | 150,0 | 100,0 | 12,0 | 12,0 | 12,0 | 28,70 | 650 | 64,0 | 1,0 | 1,00 | 233 | 31,0 | 1,0 | 1,00 |
| L 150 x 100 x 14 | 26,1 | 150,0 | 100,0 | 14,0 | 14,0 | 12,0 | 33,20 | 744 | 74,0 | 1,0 | 1,00 | 265 | 35,0 | 1,0 | 1,00 |
| L 150 x 100 x 25 | 46,3 | 150,0 | 100,0 | 25,0 | 25,0 | 12,0 | 59,00 | 2.215 | 295,0 | 381,0 | 5,39 | 433 | 87,0 | 143,0 | 2,38 |
| L 160 x 80 x 10 | 18,2 | 160,0 | 80,0 | 10,0 | 10,0 | 13,0 | 23,20 | 611 | 59,0 | 1,0 | 1,00 | 104 | 17,0 | 1,0 | 1,00 |
| L 160 x 80 x 12 | 21,6 | 160,0 | 80,0 | 12,0 | 12,0 | 13,0 | 27,50 | 719 | 70,0 | 1,0 | 1,00 | 122 | 20,0 | 1,0 | 1,00 |
| L 200 x 100 x 10 | 23,0 | 200,0 | 100,0 | 10,0 | 10,0 | 15,0 | 29,20 | 1.219 | 93,0 | 1,0 | 1,00 | 210 | 26,0 | 1,0 | 1,00 |
| L 200 x 100 x 12 | 27,3 | 200,0 | 100,0 | 12,0 | 12,0 | 15,0 | 34,80 | 1.440 | 111,0 | 1,0 | 1,00 | 247 | 31,0 | 1,0 | 1,00 |
| L 200 x 100 x 14 | 31,6 | 200,0 | 100,0 | 14,0 | 14,0 | 15,0 | 40,30 | 1.654 | 128,0 | 1,0 | 1,00 | 282 | 36,0 | 1,0 | 1,00 |
| Désignation | G kg/m | Dimensions | I cm² | Valeurs statiques | |||||||||||
| h mm | b mm | tw mm | tf mm | r mm | Axe fort | Axe faible | |||||||||
| Iy cm4 | Wely cm³ | Wply cm³ | iy cm | Iz cm4 | Welz cm³ | Wplz cm³ | iz cm | ||||||||
| L 200 x 100 x 15 | 33,7 | 200,0 | 100,0 | 15,0 | 15,0 | 15,0 | 42,90 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
| L 200 x 100 x 16 | 35,9 | 200,0 | 100,0 | 16,0 | 16,0 | 1,0 | 45,70 | 1 | 1,0 | 1,0 | 1,00 | 1 | 1,0 | 1,0 | 1,00 |
